Setting Display Orders

SKB display orders can be customized for tables which include an Order column. This is accomplished through a user defined number sequence. The order is ascending for the number sequence defined and will be the same order displayed in the Selector.

Note: Except for liquids, which are fixed alphabetically by description, the display order assigned in the SKB will be reflected in the Selector.

To enter a display order:

    1. Open a table (with an order column) to modify.

    2. In the order column (based on an ascending number sequence) enter a number to set the entry's placement. (For example, a number sequence of 1, 2, 3 will place the row with the 1 on top, next will be the row with 2, and then the row with 3 will follow.) To see some examples, click controlling the display order.



      Entering 5 for All, 10 for Chemcial process, and 15 for General industry, sets the display order.



      Modifying Ind-Chem to 15, Ind-GI to 10, changes the display order accordingly.

      Keep a gap between numbers to allow for new rows to be inserted. For example use 5, 10, 15... en lieu of 1, 2, 3....
